BLUME emergency lighting
This line for emergency lighting has since 1980, year of the beginning of production, considered by all users as one of the most reliable existing products on the market, which is also confirmed by the complaints of malfunctions equal to 0 ; this thanks to our high technological competence and high quality of material we have always used. It is from 2005, first in the international field, that the whole production has been converted into the new technology HIGHT POWER LED with the consequent increase of brightness and autonomy. This once again confirms us at the top of the category.
EMERGENCY LIGHTS
These emergency lights have anti-vandalism and dimension concepts: the fixing screws are camouflaged rendering theft difficult, while their small size make them suitable for installation visible or inside pre-existing ceiling lights; thanks to its very intense luminous flow, even the installation in the manoeuvring area is excellent. Built in self-extinguishing material, ABS and polycarbonate, it is highly shock-proof. In version SA the lamp will provide a permanent light, equal to approximately 50% of the flow in emergency. In
![](/FilesSito/images/Blume/bl964grigia.jpg)
Type
|
Input |
Flux
|
Duration
|
Measurement
|
Battery
|
Kg.
|
BLUME 964
|
230VAC |
100 lm
|
3h
|
50x60x110 mm.
|
Ni-Cd
|
0,28
|
BLUME 964SA |
230VAC |
100 lm |
3h |
50x60x110 mm.
|
Ni-Cd |
0,28 |
BLUME 964/24 |
24VAC/VDC |
100 lm |
3h |
50x60x110 mm. |
Ni-Cd |
0,19 |
SYSTEM FOR EMERGENCY LIGHT
This system comprise two separate parts: an emergency light power group (DRIVER) and HIGHT POWER LED illuminating part (LEDIERA). This allows the emergency light to be completely hidden.
This DRIVER comprises the automatism, recharge and battery. In the lift it is usually installed on the cabin roof. It is possible to have a permanent courtesy/night light (CL).
Type
|
Application with
|
Durat.
|
Measurement
|
Batt.
|
CL
|
BLUME 836
|
INPLES / AB 26
|
3h
|
50x75x125 mm.
|
Ni-Cd
|
|
BLUME 838
|
INPLES / AB 26
|
3h
|
50x75x125 mm.
|
Ni-Cd
|
•
|
The LEDIERA is built in polycarbonate and its life is virtually unlimited. It’s completed with 1.5m of special polarized cable for connection, depending on the model, at the driver or a generic power 6Vdc. It can be installed in a visible or invisible way inside the existing ceiling light.
Type
|
Application with
|
Flux
|
Measurement
|
AB26
|
BLUME 836 / 838
|
100 lm
|
55x35x15 mm.
|
AB27
|
6V
|
100 lm
|
55x35x15 mm.
|
