BLUME emergency lighting

This line for emergency lighting has since 1980, year of the beginning of production, considered by all users as one of the most reliable existing products on the market, which is also confirmed by the complaints of malfunctions equal to 0 ; this thanks to our high technological competence and high quality of material we have always used. It is from 2005, first in the international field, that the whole production has been converted into the new technology HIGHT POWER LED with the consequent increase of brightness and autonomy. This once again confirms us at the top of the category.







EMERGENCY LIGHTS

These emergency lights have anti-vandalism and dimension concepts: the fixing screws are camouflaged rendering theft difficult, while their small size make them suitable for installation visible or inside pre-existing ceiling lights; thanks to its very intense luminous flow, even the installation in the manoeuvring area is excellent. Built in self-extinguishing material, ABS and polycarbonate, it is highly shock-proof. In version SA the lamp will provide a permanent light, equal to approximately 50% of the flow in emergency.     In





Type

Input

Flux

Duration

Measurement

Battery

Kg.

BLUME 964

230VAC

100 lm

3h

50x60x110 mm.

Ni-Cd

0,28

 BLUME 964SA 230VAC 100 lm 3h

50x60x110 mm.

Ni-Cd 0,28
 BLUME 964/24 24VAC/VDC 100 lm 3h 50x60x110 mm. Ni-Cd 0,19











SYSTEM FOR EMERGENCY LIGHT

This system comprise two separate parts: an emergency light power group (DRIVER) and HIGHT POWER LED illuminating part (LEDIERA). This allows the emergency light to be completely hidden.





This DRIVER comprises the automatism, recharge and battery. In the lift it is usually installed on the cabin roof. It is possible to have a permanent courtesy/night light (CL).



Type

Application with

Durat.

Measurement

Batt.

CL

BLUME 836

INPLES / AB 26

3h

50x75x125 mm.

Ni-Cd



BLUME 838

INPLES / AB 26

3h

50x75x125 mm.

Ni-Cd





The LEDIERA is built in polycarbonate and its life is virtually unlimited. It’s completed with 1.5m of special polarized cable for connection, depending on the model, at the driver or a generic power 6Vdc. It can be installed in a visible or invisible way inside the existing ceiling light.



Type

Application with

Flux

Measurement

AB26

BLUME 836 / 838

100 lm

55x35x15 mm.

AB27

6V

100 lm

55x35x15 mm.
